Specificaties

Display

Displayresolutie

1280 x 800

Kijkhoeken

80° top/bottom, 80° left/right

Kleur achtergrondverlichting

Pure White LED

Schermhelderheid

>1200 Nits

Connectiviteit

Aan te sluiten op NMEA 2000

1x Micro-C

Aan te sluiten op pc

None

Bluetooth

Integrated Bluetooth 4.0 with support for Bluetooth Classic

Ethernetpoorten

2 x 100 Mbit, 6 max MFD's on a network

Gegevensopslag SD-kaart

2 micro SD cards up to 32GB

item beschikt over Wi Fi verbinding

Internal 802.11b/g/n and Compatible with WiFi-1 Module

N2K-PGN's

Receive only65240 ISO Commanded Address, 127245 Rudder, 127251 Rate of Turn, 127257 Attitude, 127488 Engine Parameters, Rapid Update, 127489 Engine Parameters, Dynamic, 127493 Transmission Parameters, Dynamic, 127505 Fluid Level, 127508 Battery Status, 129033 Time and Date, 129038 AIS Class A Position Report, 129039 AIS Class B Position Report, 129040 AIS Class B Extended Position Report, 129794 AIS Class A Static and Voyage Related Data, 129801 AIS Address Safety Related Message, 129802 AIS Safety Related Broadcast Message, 129808 DSC Call Information, 130313 Humidity, 130314 Actual Pressure, 130576 Small Craft Status, 65285 Temperature with Instance, 65325 Reprogramming Status, 65480 Parameter Reply, 130817 Product Information, 130820 Reprogramming Status, 130832 Fuel Used – High Resolution, 130834 Engine and Tank Configuration, 130838 Fluid Level Warning, 130842 AIS and VHF Message Transport, 130843 Sonar Status – Frequency and DSP VoltageTransmit and Receive:59392 ISO Acknowledgement, 59904 ISO Request, 60160 ISO Transport Protocol, Data Transfer, 60416 ISO Transport Protocol, Connection Management, 60928 ISO Address Claim, 126208 NMEA Group Function, 126464 Receive/Transmit PGN’s group function, 126992 System Time, 126996 Product Information, 127237 Heading/Track Control, 127250 Vessel Heading, 127258 Magnetic Variation, 128259 Speed, 128267 Water Depth, 128275 Distance Log, 129025 Position, Rapid Update, 120296 COG and SOG, Rapid Update, 129029 GNSS Position Data, 129283 Cross Track Error, 129284 Navigation Data, 129539 GNSS DOPs, 129540 GNSS Sats In View, 130074 Route and WP Service – WP List - WP Name and Position, 130310 Environmental Parameters, 130311 Environmental Parameters, 130312 Temperature, 130577 Direction Data, 61184 Parameter Command, 65292 Clear Fluid Level Warnings, 65293 LGC-2000 Configuration, 65323 Data User Group Request, 130831 EP-20 Suzuki Engine and EP-50 Storage Device Configuration, 130835 Set Engine and Tank Configuration, 130839 EP-45 Pressure Configuration, 130840 Data User Group Configuration, 130845 Parameter Handle, 130850 Event Command, 130851 Event ReplyTransmit only65287 Temperature Sensor Configuration, 65289 Trim Tab Configuration, 65290 Paddle Wheel Speed Configuration, 130818 Reprogramming Data, 130819 Request Reprogram, 130828 Set Serial Number, 130836 Fluid Level Configuration, 130837 Fuel Flow Turbine Configuration

Ondersteuning voor NMEA 0183-sentences

TX / RX - GPSReceive GGA GLL GSA GSV VTG ZDATransmit GGA GLL GSA GSV VTG ZDA GLCTX / RX - NavigationReceive RMCTransmit AAM APB BOD BWC BWR RMC RMB XTE XDRTX / RX - SonarReceive DBT DPT MTW VLW VHMTransmit DBT DPT MTW VLW VHMTX / RX - CompassReceive HDG HDT HDMTransmit HDGTX / RX - WindReceive MWV MWDTransmit MWV MWDTX / RX - AIS / DSC*Receive DSC DSE VDM*AIS sentences are not bridged to or from NMEA 2000.

Video

Output: NoInput: Composite video RCA - singlechannel via optional adaptor

Cartografie

Ondersteunde kaarten

C-MAP RevealC-MAP DiscoverC-MAP (MAX N, MAX N+)C-MAP GenesisC-MAP Precision Contour HD (AMER ONLY)Navionics (Gold, NAV+ Platinum+)Insight (Pro and HD)Lowrance Regional Mapping Partners

automatische piloot

Manoeuvres/wendpatronen

CourseHeadingWaypointPower SteerU-TurnC-TurnSpiralZigzagSquareLazy-S

Stuurstanden

CourseHeadingWaypointPower Steer

Goedkeuringen

Naleving van goedkeuringen

FCC, Industry Canada, Radio Equipment Directive, ACMA, RSM

Elektrisch

Aanbevolen stroomsterkte zekering

5A

Max. stroomverbruik

3.6A @ 13VDC with Full Backlight, Sonar on

Min. stroomverbruik

2.3A @ 13VDC with Full Backlight, Sonar on

Normaal stroomverbruik

2.3A @ 13VDC withwith Full Backlight, Sonar on

Voedingsspanning

12 v DC (10.8-17VDC)

Omgeving

Bedrijfstemperatuurbereik

5°F to 131°F (-15°C to 55°C )

Opslagtemperatuurbereik

4°F to 140°F (-20°C to 60°C )

Schokabsorptie

100,000 cycles of 20 G

Vochtigheid

IEC 60945Damp Heat 150°F (66°C) at 95% Relative Humidity (48 hrs)

Waterbestendigheid

IPX7 with card door closed

GPS

Correctie

DGPS, WAAS

GPS-ontvangstkanalen

16

Positienauwkeurigheid

20m RMS

Tijd tot eerste positiebepaling

30s

Updatesnelheid

10 Hz

MFD

AIS

AIS Chart and Radar overlay. Target vessel details.

Digital switching

CzoneNaviop

Geschikt voor sonar

Integrated: CHIRPBroadbandActive Imaging DownScanActive Imaging SideScanActive Imaging HD DownScanActive Imaging HD SideScanCompatible with:ActiveTargetActiveTarget2S3100 SonarHubStructureScanStructureScanHDStructureScan3DLiveSight (requires PSI-1 module)

GPS

10 Hz GPS/GLONASS WAAS/EGNOS/MSAS

Inclusief cartografie

C-MAP World Background (ROW models)Navionics basemap (AMER and ROW models)

Interne opslag

8.0 GB Internal

Multimedia

SonicHubSonicHub2FusionLink productsany NMEA 2000 compliant Marine Aduio products

Stuurautomaat

Outboard PilotNAC-1NAC-2Ghost Trolling MotorMotorGuide Xi5/Xi3 Trolling Motor **requires Motorguide PinPoint Gateway

Waypoints, routes, tracks

3000 Waypoints100 Routes100 Trails with up to 10,000 points per trail

Weer

SiriusXM via WM-3 (USA only)SiriusXM via WM-4 (USA only)

Fysiek

Afmetingen (H×B×D)

13.68" (347.5 mm) x 9.00" (225.5 mm) x 3.26" (82.9 mm)

Gewicht

5.76 lb (2.61 kg)

Kompasbescherming

65 cm (2.1 ft)

Type montage

Gimbal BracketFront Dash Flush MountRear Dash Flush Mount

Ander

Garantieperiode

2 Year + 3 additional years ofupgrade optionsTotaling 5 years

Interface

Touchscreen:Full Multi-touch touchscreenKeypad:8-way directional keypadZoom +/-ExitEnterMenuWaypointPower/Light4 - User Programmable Quick Access Keys

Talen

Standard Language Pack: Afrikaans/Afrikaans, Danish/Dansk, German/Deutsch, English (US), English (UK), Spanish/Español, Finnish/Suomi, French/Français, Greek/Ελληνικά, Icelandic/íslenska, Italian/Italiano, Dutch/Nederlands, Norwegian/Norsk, Portugese (Brazil)/Português (BR), Portugese (Portugal)/Português (PT), Swedish/SvenskaAsian Language Pack: English (US), English (UK), Japanese/日本語, Korean/한국어, Thai/ภาษาไทย, Chinese - (simplified) China/简体中文, Chinese - (traditional) Taiwan/繁體中文Eastern European Language Pack:Bulgarian/Български, German/Deutsch, Estonian/Eesti, English (US), English (UK), Spanish/Español, French/Français, Hebrew/ عبری , Croatian/ Hrvatski, Hungarian/ Magyar, Italian/Italiano, Lithuanian/Lietuvos, Latvian/ Latvijas, Polish/Polski, Slovak/ Slovensky, Turkish/TürkçeRussia/Ukraine Language pack: German/Deutsch, English (US), English (UK), Spanish/Español, Italian/Italiano, Russian/Русский, Ukraine/ УкраїнськаMiddle Eastern Language Pack: Arabic (UAE)/ العربية , German/Deutsch, English (US), English (UK), Farsi/ فارسی , French/Français, Italian/Italiano
